SPECIFICATIONS

　　MODEL

　　DRIVE X 纏繞機

　　PERFORMANCE

　　Maximum wrapping Speed 20-30 loads/Hour

　　Load Size Diagonal 1753mm(Recommended)

　　Maximum Wrapping Height 2200mm(2800mm Optional)

　　Maximum Load Weight 2000kg

　　TURNTABLE SYSTEM

　　Turntable Speed 12RPM

　　Turntable size 1650mm

　　Turntable Drive 1PH

　　PERFORMANCE FEATURES

　　Film Cut and Clamp Automatic

　　Pallet Grip Standard

　　Intelli-Sensor Standard

　　Standard Film Width 500mm

　　Constant Film Delivery Force Standard

　　Standard Pre-Stretch 300%

　　Wrap Force Variable(Electric)

　　Film Capacity 250mm Roll Diametery

　　Film Delivery System Power Roller-Stretch Plus

　　Remote Control system Standard

　　EIGHT AND SIZE纏繞機

　　Machine Weight 660kg

　　Machine Size L2700W 1650 H2475

　　SERVICE REQUIREMENTS

　　Cotrol System SIEMENS Control System

　　V0ltage 220V 16A
